- ASC-MS空压转角缸附磁石感应
- 【Brief】：
- This product is used in special machines and MC fixtures for mass-produced parts to improve production efficiency.
- The main function is that when the air cylinder moves, the middle pressure plate will rotate to the design angle during the piston down-pressure stroke, and then press down along the straight line to clamp the workpiece.
- It is recommended that air pressure angle cylinder be used. A. B inlet should be equipped with flow control valve to avoid excessive speed and to avoid clamping workpiece during angle stroke, which may cause damage to cylinder and internal parts.
- When the length of the pressing plate needs to be increased, please do not exceed 1.5 times the original length.Cylinder block is made of aluminium alloy with hard film treatment, smooth inner surface and long service life.
- 【Series】：空压转角缸
